Tektronix TDS3034B Reference

35
Hard Copy System Menu (Utility > System: Hard Copy )
Bottom Side Description
Format Choose the correct hard copy
format for your printer.
Options
Portrait Prints in a portrait orientation.
Landscape Prints in a landscape orienta-
tion.
Compression Turn on or off hard copy file .gz
compression format.
Ink Saver
Off Prints the display colors.
On Prints colors optimized for
printing on white paper.
Preview Shows a preview of the hard
copy colors on the display.
Port
Centronics Uses the parallel printer port.
GPIB Uses the GPIB port.
RS-232 Uses the RS-232 port.
File Saves the hard copy to the
floppy disk.
Ethernet Uses the Ethernet LAN port.
Clear Spool Stops a hard copy in progress.
Clears the print spooler.
36
Calibration System Menu
Bottom Side Description
System Cal
Signal Path Compensates the signal paths
to obtain best measurement
accuracy.
Factory Cal Used to calibrate the oscillo-
scope. This is a service function
only.
Cal Due
Control
Notify After
Hours of Op-
eration
Sets the number of hours of
operation before notifying you
that a calibration is due.
Notify After
Years of
Elapsed Time
Sets the number of years before
notifying you that a calibration is
due.
Signal Path Compensation. You can run the Signal Path
Compensation routine anytime but you should always
run the routine if the ambient temperature changes by
10 °C or more.
