Performance Verification
TDS3000B Series Service Manual
4-9
18. Push the -- m o r e -- screen button until you can select the Pk-Pk measure-
ment.
19. Set the vertical SCALE to 100 mV/div.
20. Set the output frequency of the leveled sine wave generator to 50 kHz.
21. Set the output amplitude of the l eveled sine wave generator so the peak-to-
peak measurement is between 599 mV and 601 mV.
22. Set the horizontal SCALE to 10 ns/div.
23. Set the output frequency of the leveled sine wave generator to the frequency
shown in the table below.
Oscilloscope model Frequency
TDS301xB 100 MHz
TDS302xB 200 MHz
TDS303xB 300 MHz
TDS304xB 400 MHz
TDS305xB 500 MHz
TDS306xB 600 MHz
24. Verify that the peak-to-peak measurement is ≥425 mV.
25. Push the waveform off
button.
26. Repeat steps 11 through 25 for each channel of the oscilloscope (not
including the external t rigger input).
