Getting Acquain
ted with Your Instrument
About the Matrix Test Signal
The M atrix test signal is supplied on the accessory signal source disks included with this product. There is a Matrix signal for
Options SD and HD and a Matrix signal for Option VGA. The Matrix signal incorporates all analog video signal requirements
into different line numbers within one test pattern field. Using a single test pattern eliminates the need to change test
signals when doing different measurements. All you need to do is specify line numbers on which measurements are taken.
Use the setup file (.vmset) that matches the format of the Matrix test signal you are using; this provides appropriate line
numbers as default settings for each measurement type. See the VM Series Video Measurement System User Manual for
a full description of the files on the signal source disks.
Option SD/HD Matrix signal
Elements of Option SD/HD Matrix signal
Signal name Format Signal name Format Signal nam e Format
1. Color bars
All 7. YPbPr sweep time YPbPr 13. Valid ramp All
2. RGB pulse bars RGB
8. YPbPr sweep
Frequency
YPbPr 14. YPbPr shallow
ramp
YPbPr
3. RGB frequency
sweep
RGB
9. YPbPr multiburst YPbPr
15. RGB shallow
ramp
RGB
4. RGB
time sweep
RGB
10. YPbPr multiburst YPbPr
16. Fl
at field 7.5%
All
5. RGB
multiburst
YPbPr
11. RG
Bcrosstalk
RGB 17. Fl
at field 50%
All
6. YPbPr pulse bars YPbPr 12. YPbPr crosstalk YPbPr
18. Fl
at field 100%
All
24 VM Series Video Measurement System Quick Start User Manual
