Specifications
TDS5000B Series Specifications and Performance Verification
1-7
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteri sti c Description
≥30:1 at >100 MHz up to the rated bandwidth for any two channels with
equal V/div settings
Digitizers 8-bit resolution
TDS5032B, TDS5052B Two separate digitizers, each channel sampled
simultaneously
TDS5034B, TDS5054B,
TDS5054BE, TDS5104B
Four separate digitizers, each channel sampled
simultaneously
Sensitivity range Fine adjustment available wi th ≤1% resolution
1MΩ 1 mV/div to 10 V/div, in a 1-2-5 sequence
50 Ω 1 mV/div to 1 V/div, in a 1-2-5 sequence
n Analog bandwidth SCALE range Bandwidth
TDS5032B, TDS5034B 1mV/divto1.99mV/div DC to 150 MHz
2mV/divto4.98mV/div DC to 250 MHz
5mV/divto1V/div DC to 350 MHz
DC 50 Ω coupling; bandwidth limit set to Full; operating ambient ≤30 °C;
derated by 2.5 MHz/°C above 30 °C
TDS5052B, TDS5054B, TDS5054BE 1mV/divto1.99mV/div DC to 175 MHz
2mV/divto4.98mV/div DC to 300 MHz
5mV/divto1V/div DC to 500 MHz
DC 50 Ω coupling; bandwidth limit set to Full; operating ambient ≤30 °C;
derated by 2.5 MHz/°C above 30 °C
TDS5104B 1mV/divto1.99mV/div DC to 175 MHz
2mV/divto1V/div DC to 1 GHz
DC 50 Ω coupling; bandwidth limit set to Full; operating ambient ≤30 °C;
derated by 5 MHz/°C above 30 °C
Analog bandwidth selections 20 MHz, 150 MHz, or Full
