Tektronix TDS5104B Specification And Performance Verification Technical Reference

Specifications
TDS5000B Series Specifications and Performance Verification
1-21
Table 1- 8: Power source specifications
Characteri sti c Description
Source voltage and frequency 100 to 240 V
RMS
±10%,47Hzto63Hz
Power consumption
≤220 Watts
Fuse rating Internal t o power supply; not serviceable by user
Nonvolatile memory retention CMOS settings stored for a period of 3 years without
instrument connection to power mains
Calibration settings and error log ent ri es stored for
1 million cycles or 20 years
Overvoltage Category Overvoltage Category II (as defined in IEC61010-1/A2)
Table 1- 9: Mechanical specifications
Characteri sti c Description
Weight
Benchtop configuration 24.75 lbs (10.2 kg) oscilloscope only
56.5 lbs (25.6 kg) when packaged for domestic shipment
Rackmount kit 5 lbs (2.3 kg) rackmount conversion kit
8 lbs (3.6 kg) kit packaged for domestic shipment
Dimensions
Benchtop configuration Height: 14.2 in (360.7 mm)
Height:, feet extended:14.25 in (362 mm)
Width: 17.6 in (447 mm )
Depth: 11.35 in (288.3 mm)
Rackmount configuration
(Option 1R)
Height: 10.5 in (267 mm)
Width: 19 in (483 mm)
Depth: 9.1 in (231 mm)
Cooling Fan-forced air c irculation with no air filter
Required clearances Top 0in(0mm)
Bottom 0.25 in minimum or
0 in (0 mm) when standi ng
on the feet
Left side 3in(76mm)
Right side 0in[5in(126mm)required
to access CD-ROM]
Front 0in(0mm)
Rear 0in(0mm)
