Specifications
TDS5000B Series Specifications and Performance Verification
1-13
Table 1- 3: Horizontal and acquisition system specifications
Characteri sti c Description
Acquisition modes Sample, Peak detect, Hi Res, Average, and Envelope
Fast acquisition rate Up to 100,000 waveforms-per-second with Fast
Acquisition mode on
Up to 130 waveforms-per-second with Fast Acquisition
mode off
Minimum record length 500 points
Maximum record length Depends on number of active channels and amount of
memory installed
Standard 2,000,000 points (3 or 4 channels)
4,000,000 points (2 channels)
8,000,000 points (1 channel)
Option 3M installed 4,000,000 points (3 or 4 channels)
8,000,000 points (2 channels)
16,000,000 points (1 channel)
Sample rate range, real-time Number acquired channels Sample rate range
TDS5032B, TDS5034B,
TDS5052B, TDS5054B,
TDS5104B
1 1.25 S/s to 5 GS/s
2 1.25 S/s to 2.5 GS/s
3or4 1.25 S/s to 1.25 GS/s
TDS5054BE 1,2,3, or 4 1.00 S/s to 1.00 GS/s
Equivalent-time sample rate or
interpolated waveform rate range
Listed values depend on the number of channels in use,
horizontal scale, and resolution settings.
Equivalent-time acquisition can be enabled or disabled.
When disabled, waveforms are interpolated at the fastest
time base settings.
TDS5032B, TDS5034B,
TDS5052B, TDS5054B,
TDS5104B
2.5 GS/s to 250 GS/s
TDS5054BE 2 GS/s to 200 GS/s
Seconds/division range (s/div x 10) to 1,000 s
Horizontal delay range 16 ns to 250 s
n Long term sample rate and
delay time accuracy
±15 ppm over any ≥1 ms interval
RMS aperture uncertainty, typical
≤ [3 ps + (0.1 ppm × record duration)] for real-time or
interpolated records with a duration ≥1 minute
