Tektronix TDS5104B Specification And Performance Verification Technical Reference

Specifications
TDS5000B Series Specifications and Performance Verification
1-17
Table 1- 4: Trigger specifications (Cont .)
Characteri sti c Description
Width type Minimum difference
between upper and lower
limits = 1 ns
2 ns + 5% of upper limit
setting
Timeout type Minimum timeout time =
1ns
2 ns + 5% of timeout set-
ting
Transition type Minimum transition time =
600 ps
8.5 ns + 5% of transition
time setting
Pattern type, typical Minimum time the pattern is
true = 1 ns
1ns
Logic Not applicable 1ns
Events Delay 1 ns (single channel ) Not applicable
State type, typical Minimum true time before
clock edge = 1 ns
Minimum true time after
clock edge = 1 ns
1ns
Setup/Hold type, typical Minimum clock pulse width
from active edge to inactive
edge
Minimum clock pulse width
from inactive edge to active
edge
3 ns + hold ti me setting 2ns
Setup and Hold parameters Limits
Setup time (time from data
transition to clock edge)
--100 ns minimum
+100 ns maximum
Hold time (time from clock
edge to data transition)
--1 ns minimum
+102 ns maximum
Setup time + Hold time
(algebraic sum of the two
settings)
+2 ns minimum
+202 ns maximum
