Removal and Installation Procedures
6-- 48
TDS7104 & TDS7054 Service Manual
J691 J690
J190
T--15 Torx
screw (9)
5/16 Nut
post (2)
3/16 Nut
post (2)
Chassis
support
PPC Processor
board
Phillips
screw (2)
Support
bracket
Figure 6--28: PPC Processor board removal
