Tektronix TDS6000 Series Service Manual

Specifications
1-6
TDS7104 & TDS7054 Service Manual
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
n Anal og bandwidth DC 50 Ω coupling, bandwidth limit set to Full, operating
ambient ≤30 °C, derated by 2.5 MHz/°C above 30 °C
SCALE range Bandwidth
1mV/divto1.99mV/div TDS7054: DC to 450 MHz
TDS7104: DC to 500 MHz
2mV/divto4.98mV/div TDS7054: DC to 500 MHz
TDS7104: DC to 600 MHz
5mV/divto9.95mV/div TDS7054: DC to 500 MHz
TDS7104: DC to 750 MHz
10 mV/div to 1 V/div TDS7054: DC to 500 MHz
TDS7104: DC to 1 GHz
Analog bandwidth limit, typical Selectable between 20 MHz, 200 MHz, or Full
Lower frequency limit, AC coupled <10Hzfor1MΩ, reduced by a factor of ten when using
a 10X probe; <200 kHz for 50 Ω
Calculated rise time, typical DC 50 Ω coupling, bandwidth limit set to Full
SCALE range Rise time
1mV/divto1.99mV/div TDS7054: 890 ps
TDS7104: 800 ps
2mV/divto4.98mV/div TDS7054: 800 ps
TDS7104: 667 ps
5mV/divto9.95mV/div TDS7054: 800 ps
TDS7104: 533 ps
10 mV/div to 1 V/div TDS7054: 800 ps
TDS7104: 400 ps
