Appendix A: Specifications
A-12
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
TDS7104 & TDS7054 DC 50 Ω coupling, bandwidth limit set to Full
SCALE range Rise time
1mV/divto1.99mV/div TDS7054: 890 ps
TDS7104: 800 ps
2mV/divto4.98mV/div TDS7054: 800 ps
TDS7104: 667 ps
5mV/divto9.95mV/div TDS7054: 800 ps
TDS7104: 533 ps
10 mV/div to 1 V/div TDS7054: 800 ps
TDS7104: 400 ps
Lower frequency limit, AC coupled
TDS7104 & TDS7054
<10Hzfor1MΩ, reduced by a factor of ten when using a 10X probe; <200 kHz for
50 Ω
