Tektronix TDS7104 User Manual

Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-21
Table A- 3: Horizontal and acquisition system specifications (Cont.)
Characteristic Description
Frame length and maximum number of frames
CSA7404, CSA7154, TDS7404,
TDS7254, &TDS7154
Maximum number of frames for Sample or Peak Detect acquisition mode,
depending on memory option instal led
Frame length Maximum number of frames
50 points Standard: 648--5872
Option 2M: 2660--24088
Option 3M: 5321--48192
Option 4M: 5321--48192
500 points Standard: 580--3560
Option 2M: 2381--14632
Option 3M: 4765--29272
Option 4M: 4765--29272
5000 points Standard: 163--720
Option 2M: 669--2968
Option 3M: 1339--5936
Option 4M: 1339--5936
50,000 points Standard: 19--80
Option 2M: 81--328
Option 3M: 163--656
Option 4M: 163--656
500,000 points Standard: 2--8
Option 2M: 8--32
Option 3M: 16--64
Option 4M: 16--64
TDS7104 & TDS7054 50 point s Standard: 645--2936
Option 2M: 2657--12044
Option 3M: 5318--24096
500 points Standard: 445--1780
Option 2M: 1829--7316
Option 3M: 3659--14636
5000 points Standard: 90--360
Option 2M: 371--1484
Option 3M: 742--2968
50,000 points Standard: 10--40
Option 2M: 41--164
Option 3M: 82--328
500,000 points Standard: 1--4
Option 2M: 4--16
Option 3M: 8--32
