Tektronix TDS7104 Service Manual

Specifications
TDS7104 & TDS7054 Service Manual
1-9
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Effective bits, typical Sine wave input at the indicated frequency and pk-pk
amplitude, at 50 mV/division and 25 °C
Signal and input conditions Effective bits
TDS7054 1MHz,9.2div,2GS/s
sample rate, Sample
acquisition mode
6.8 bits
1MHz,9.2div,10MS/s
sample rate, HiRes acquisi-
tion mode
8.7 bits
500 MHz, 6.5 div, 2 GS/s
sample rate, Sample
acquisition mode
6.8 bits
TDS7104 1MHz,9.2div,10GS/s
sample rate, Sample
acquisition mode
6.6 bits
1MHz,9.2div,10MS/s
sample rate, HiRes acquisi-
tion mode
8.7 bits
1GHz,6.5div,10GS/s
sample rate, Sample
acquisition mode
5.5 bits
