Performance Verification
4-2
TDS7104 & TDS7054 Service Manual
Conventions
Throughout these procedures the following conventions apply:
H Each test procedure uses the following general format:
Title of Test
Equipment Required
Prerequisites
Procedure
H Each procedure consists of as many steps, substeps, and subparts as required
to do the test. Steps, substeps, and subparts are sequenced as follows:
1. First Step
a. First Substep
H First Subpart
H Second Subpart
b. Second Substep
2. Second Step
H In steps and substeps, the lead-in statement in italics instructs you what to
do, while the instructions that follow tell you how to do it, as in the example
step below:
Initialize the oscilloscope: Push the front-panel DEFAULT SETUP button.
H Where instructed to use a control in the display or a front-panel button or
knob, the name of the control, button, or knob appears in boldface type.
Where instructed to make or verify a setting, the value of the setting also
appears in boldface type.
STOP.TheSTOP notation at the left is accompanied by information you must read
to do the procedure properly.
H The term “toolbar” refers to a row of buttons at the top of the display. The
term “menu bar” refers to a row of menus at the top of the display. You can
switch between toolbar and menu bar operating modes by pushing the button
near the top right corner of the display. See Figure 4--1.
