Tektronix THDP0100 Installation And Safety Instructions

Operating Considerations
Operating Considerations
Specification THDP0100 THDP0200 TMDP0200
Bandwidth 100 MHz 200 MHz 200 MHz
Maximum
measurable
differential
voltage
1
600 V Range:
600 V DC + peak AC
450 V
rms
6000 V Range:
6000 V DC + peak AC
3000 V
rms
150 V Range:
150 V DC+ peak AC
100 V
rms
1500 V Range:
1500 V DC + peak AC
1000 V
rms
75 V Range:
75 V DC+ peak AC
50 V
rms
750 V Range:
750 V DC + peak AC
500 V
rms
Maximum
common mode
voltage and
input voltage-to
-earth (V
rms
)
2
±6000 V DC + peak AC
2300 V CAT I
1000 V CAT III
±1500 V DC + peak AC
1000 V CAT II
600 V CA T III
±750 V DC + peak AC
550 V CA T I
300 V CAT III
Maximum Rated
Over-Voltage
Transient
(OVT)
3
4600 V
pk
NA 3220 V
pk
1
Beyond these limits, the output could be clipped. (See Figure 1 on page 10.)
2
The Common Mode and input voltage-to-earth ratings are the maximum ratings of each
input lead (+/-) to ground. (See Figure 1 on page 10.)
3
Applies to CAT I ratings only (both ranges). OVT peak is measured on top of the Peak
Working Voltage.
