TLA5000 Series Service Manual
6-37
Troubleshooting
WARNING. Before performing this or any other procedure in this manual, read
the General Safety Summary and Service Safety Summary found at the
beginning of this manual.
To prevent possible injury to service personnel or damage to electrical compo-
nents, please read Preventing ESD on page 6--1.
This section contains information and procedures designed to help you isolate
faults to within the logic analyzer. The process is as follows:
H Do Check for Common Problems on page 6--38 to eliminate easy-to-find
problems first.
H Do Diagnostics, beginning on page 6--39, to locate the failed replaceable part
within the logic analyzer.
For assistance, contact your local Tektronix Service Center.
Service Level
This section supports isolation of faults within the logic analyzer to the
replaceable-part level. In most cases, faults are isolated to circuit boards or
assemblies, but not to individual components on those boards.
