Troubleshooting
TLA5000 Series Service Manual
6-43
Table 6- 4: Beep codes (Cont.)
Beeps Description
10 CMOS shutdown register test error
11 Invalid BIOS (for example, POST m odule not f ound, etc.)
Restoring or Reinstalling Software
Most of the software comes factory-installed when you receive your logic
analyzer. You only need to refer to this section if you reinstall the software.
These instructions refer to resetting the controller BIOS, restoring the operating
system (hard disk image), and reinstalling the application software.
Setting Up the TLA5000 Controller BIOS
This procedure is necessary when the BIOS settings are corrupted or lost. To
configure the Controller BIOS, complete the following steps:
1. Power on the logic analyzer and press the F2 function key before the logic
analyzer boots the Windows operating system.
2. Press the F9 function key, select Yes, and then press Enter to set all settings
to their default values. Verify that the hard disk was auto-recognized and that
the correct size of the hard disk is displayed in the Primary Master setting.
3. Using the arrow keys, navigate to the Advanced page.
4. Under Peripheral Configuration, perform the following:
a. Set the Parallel Port Mode to ECP
b. Set the Audio to Disabled.
5. Under Diskette Configuration, set the Diskette Controller to Disabled.
6. Under Video Configuration, set the Primary Video Adapter to PC I.
7. Press the F10 function key to exit and save the BIOS setup.
