Tektronix WFM6120 Technical Reference

Specifications
Table 10: SDI Li
ghtning and Diamond Modes
Characteristic Performance requirement Reference information
Vertical Gain Accuracy ± 0.5%
Fully digital
system
Diamond
RGB deflection axis indicated. Upper and
lower halves are separated, to see negative
signals
Electronic
Graticule
Display
Lightning
Displays si
gnal components as follows: Y
vertically Pb horizontally on top half of display
P
r
horizontally on bottom half of display
High Limit +630 mV to +756 mV in 1 mV steps
Detection
Level
Low Limit -50 mV to +
35 mV in 1 mV steps
Detection Level Accuracy ± 3.5 mV
Diamond Area Threshold Range
0% to 10%
Table 11: Data Mode
Characteristic Performance requirement Reference information
Digital Waveform Non-interpolated waveform display. Cursor
identifies selected sample value (hex,
decimal, binary). Cursor inserted on picture
monitor output shows selected line
Digital List
Sequential list of sample values in table
format. Cursor identifies selected sample
Display Format
HEX, DEC, BIN
Table 12: Composite Vector Mode
Characteristic Performance requirement Reference information
X1 Gain ±1%
Displayed
Horizontal and
Vertical Gain
Accuracy
X5 Gain ±1%
Display to Graticule Registration Centered in target, +0.5 box diameter
With the color bar black/white display dot
centered in target. B oxes are 2% targets
Vector Display B-Y is displayed on horizontal axis and R-Y
is displayed on vertical axis
Bandwidth, Typical 360 kHz
Horizontal to Vertical Bandwidth
Matching
< 0.5° at 500 kHz and 2 MHz
Composite Vector Dot Reference Shows “true” zero subcarrier reference
R-Y B-Y Axis Orthogonality.
Typical
± 0.1°, implemented digitally
Waveform Monitors Specifications and P erformance Verification 13
