Tektronix WFM6120 Technical Reference

Test Records
Table 57: WFM6120, WFM7020, and WFM7120 Waveform Monitor Video Performance Test Record (cont.)
Performance Test Minimum Incoming Outgoing Maximum
YPbPr Pass
RGB
Pass
Composite
Pass
SD SDI Serial Output
Amplitude
760 mV 840 mV
SD VITC Decoding
Functionality
Pass
SD Cable Meter
SDI A Input (Short
Cable)
0m 17m
SDI A Input (Long
Cable)
76 m 127 m
SDI B Input (Short
Cable)
0m 17m
SDI B Input (Long
Cable)
76 m 127 m
SD Equalized Eye
Gain
Pass
SD Jitter Noise Floor and Bounce
Jitter Noise Floor Pass
SD Jitter Readout Accuracy
Jitter Trace Pass
Jitter Readout Pass
Test Record - Option CPS
Table 58: WFM7120 Waveform Monitor Video Performance Test Record (Options CPS)
Instrument Serial Number: Certificate Number:
Temperature:
RH %:
Date of Calibration:
Technician:
Performance Test Minimum Incoming Outgoing Maximum
Composite Analog
Frequency Response
99%
(7 mV)
101%
(–7 mV)
Composite Analog
Delay Variation Over
Frequency (Group
Delay)
-10ns
(–7.1 mV)
+10ns
(7.1 mV)
Composite Analog
PulsetoBarRatio
99%
(–7 mV)
101%
(7 mV)
48 Waveform Monitors Specifications and Performance Verification
