Tektronix WFM6120 Technical Reference

Specifications
Table 36: Serial Video Output (Serial Out/SDI PixMon) (cont.)
Characteristic Performance requirement Reference information
SD 400 ps minimum, 800 ps maximum, 20% to
80%
Rise and Fall
Time, Typical
HD
220 ps maximum, 20% to 80%
Return Loss, Typical
15 dB to 1.5 G Hz
10 dB to 3.0 GHz (option 3G only)
Table 37
: External Reference
Characteristic Performance requirement Reference information
Input Ty
pe
Passive loop-through, 75 Ω compensated
Operational
Locks t
o analog bi-level and tri-level
signals of formats. (See Table 45.)(See
Table 46.)(See Table 47.) R eference must
have a
frame rate compatible with input.
WFM mode and Line Select derive timing
from the external sync information
Pictu
re mode and Data mode do not use
timing from the external reference
With Simultaneous inputs, External
Refe
rence settings apply to both channels
Anal
og Sync Format
PAL
1080
i60Hz
720p 59.94 Hz
NTSC
108
0i 59.94 Hz
1080p 23.98 Hz
1080p 24 Hz
72
0p 50
720p 60
1080i 50
10
80sf 23.98
1080sf 24
Input Signal Level, Typical
–
6dBto+6dB
DC Input Impedance 20 kΩ
Maximum Operating Input Voltage,
Typical
±5VDC
Absolute Maximum Input Voltage,
Typical
±5VDC
Inband Input Impedance, Typical
±15kΩ
32 Waveform Monitors Specifications and Performance Verification
