Incoming Inspection
Incoming Inspection
This section contains functional/operational checks appropriate to an incoming
inspection.
The waveform monitor must have been operating for a warm-up period of at least
20 minutes, and must be operating at an ambient temperature. (See Table 44
on page 35.)
Use the following procedures to check the basic functionality of WFM6120,
WFM7020, a
nd WFM7120 Waveform Monitors. The checks are arranged by
model and option so that you can choose the sections that are appropriate for your
instrument. The last two sections are for less critical waveform monitor features:
the ground closure and Ethernet ports. You need only test these if you intend to
use them. In general, you should test in the order presented, since later tests might
depend on items checked in the earlier tests.
Required Equipment
The following equipment is required to perform the incoming inspection
proce
dure.
Table 61: Required Test Equipment
Test Equipm ent Requirements Example
XGA Monitor Computer monitor capable of 1024 x 768
x60Hzscanrate
75 Ω coaxial cables
(3 required)
General purpose digital video
Male-to-male BNC connectors 1 or
2 meters long
Belden 8281.
Tektronix part numbers 012-0159-00 or
012-0159-01
75 Ω Terminator for Analog Video
Male connector, Precision Tektronix part number
011-0102-03
Analog audio breakout cable (required for
Audio Options AD and DDE)
DB62 to XLR I/O
Tektronix part number
012-1688-00
Dolby bit-stream generator
Generate Dolby Digital, Dolby E and PCM
bit streams at 48 kHz.
AES3ID-1995/SMPTE 276M output
(75 Ω BNC)
Dolby Laboratories DM100 Bitstream
Analyzer. (Option DDE)
58 Waveform Monitors Specifications and Performance Verification
