Tektronix WFM6120 Technical Reference

Specifications
Table 30: Picture Monitor Outputs (VGA Pix Mon) (cont.)
Characteristic Performance requirement Reference information
SD
Y-to-Pb and Y-to-Pr ±5.0 ns
Interchannel
Timing Match,
Typical
HD Y-to-Pb and Y-to-Pr ±4.0 ns
SD
–300 mV
Sync
Amplitude
Accuracy,
Typical
HD 300 mV on positive and negative excursions
SD
70 dB to 5.5 MHz 58 dB to 100 MHz
RMS noise on quiet line, relative to 700 mV
Signal to Noise
Ratio, Typical
HD 58 dB to 30 MHz 55 dB to 250 MHz
RMS noise relative to 700 mV
Return Loss on BNCs, Typical
>20dBto30MHz
Transcoder Accuracy 9 bit
Composite M ode When using composite input only. Sourced
on Green channel of connector
Composite Amplitude, Typical 1 V ±5% including sync and 100% white
video
Composite Offset, Typical
±100 mV
Composite mode SNR,Typical 60 dB RMS to 700 mV with 20 MHz BW
Table 31: LCD Display
Characteristic Performance requirement Reference information
Horizontal 13 cm
Display Area
V
ertical
1
0cm
Resolution
1
024 (H) x 768 (V) pixels
Color Palette 6 bits per component. LSB is dithered to
improve picture
Pixel Defects
≤ 6 bad pixels
Table 32: External XGA Output (EXT DISPLAY)
Characteristic Performance requirement Reference information
Content Identical to front-panel LCD display
Output Levels 0.7 V or 1 V for RGB signals, selectable.
Fixed 5 V for H and V sync signals
Resolution
1024 (H) x 768 (V) pixels
28 Waveform Monitors Specifications and Performance Verification
