Tektronix WFM6120 Technical Reference

Test Records
Table 58: WFM7120 Waveform Monitor Video Performance Test Record (Options CPS) (cont.)
Performance Test Minimum Incomin g Outgoing Maximum
Composite Analog
Field Rate Tilt
–0.5%
(-3.5 mV)
+0.5%
(+3.5 mV)
Composite Analog
Line Rate Tilt
-0.5%
(–3.5 mV)
+0.5%
(+3.5 mV)
Composite Analog
Input DC Offset with
Restore Off
–10 mV 10 mV
Composite Analog
Input Clamp O ff Check
Pass/Fail
Composite Analog Input DC Restore Hum Attenuation
DC Restore Off
Pass
Fast Mode
(0mV) 5%
(35 mV)
Slow Mode 90%
(643 mV)
110%
(785 mV)
Composite Analog
Vertical Measurement
Accuracy
707.71 mV 722.01 mV
External Reference
Lock Range
–50 ppm 50 ppm
VITC Decoding
Functionality
Pass
Test Record - Options AD and DDE
Table 5 9: WFM7120 Waveform Monitor Audio Options AD and DDE Test Record
Instrument S erial Number: Certificate Number:
Temperature:
RH %:
Date of Calibration:
Technician:
Performance Test Minimum Incomin g Outgoing Maximum
AES Audio Input Sample Rate
AESA1-2In(96kHz)
pass
AESA3-4In(96kHz)
pass
AESA5-6In(96kHz)
pass
AESA7-8In(96kHz)
pass
AESA1-2In(35kHz)
pass
AESA3-4In(35kHz)
pass
AESA5-6In(35kHz)
pass
