Tektronix WFM6120 Technical Reference

Specifications
Table 40: Remote Port (cont.)
Characteristic Performance requirement Reference information
Pin # S ignal 1 Out; GND 2 In; Time Code
Positive (LTC input) 3 In; Time Code Negative
(LTC input) 4 Out; GND 5 Out; Ground
Closure Output 6 In; Preset Recall A1 7 In;
Preset Recall A2 8 In; Preset Recall A3 9 In;
Preset Recall A4
Hex Binary
Pins
9,8,7,6
Direct mode
selection
F 1111
none
E 1110 Preset
1
D 1101 Preset
2
C
1100
B 1011 Preset
3
A 1010
9 1001
8 1000
7
0111 Preset
4
60110
5
0101
4 0100
3 0011
2 0010
1 0001
Connector Pin Assignments
0 0000
Table 41: Power Source
Characteristic Performance requirement Reference information
Electrical Rating
100 - 240 VAC ±10%, 50/60 Hz 115
Watts max.
Supply Connection
Detachable cord set
Power Consumption, Typical 50 to 110 VA at 110 or 240 VAC
Surge, Ty pical
7.5 Amps at 90 V 10 Amps at 240 V
Fuse Rating T3.5, 250 V
Not operator replaceable. Refer servicing
to qualified service personnel
34 Waveform Monitors Specifications and Performance Verification
