Tektronix WFM6120 Technical Reference

Test Records
Test Record - All Instruments
If you are testing a WFM6120 or a WFM7000 without Option HD, skip the HD
entries in the record. Complete the other entries, which are common to all models.
Table 56: WFM6120, WFM7000, and WFM7120 Waveform Monitor Video Performance Test Record
Instrument Serial Number: Certificate Number:
Temperature:
RH %:
Date of Calibration:
Technician:
Performance Test Minimum Incoming O utgo ing Maximum
HD SDI Input Level Low and High (HD)
Input A, Low Level
90%
(720 mV)
Input A, High Level
110%
(880 mV)
Input B, Low Level
90%
(720 mV)
Input B, High Level
110%
(880 mV)
EDH and HD SDI Input Equalization Range (HD)
EDH Pass
Input A 20 d B
Input B 20 d B
HD SDI Loop Through Isolation (HD)
Pass
HD PixMon Frequency R esponse
–0.92 dB (–10%) +0.82 dB (+10%)
HD Cable Meter (HD)
SDI A Input (Short Cable)
0m 17m
SDI A Input (Long Cable)
76 m 127 m
SDI B Input (Short Cable)
0m 17m
SDI B Input (Long Cable)
76 m 127 m
HD Jitter Noise Floor and Bounce (HD)
Jitter Noise Floor Pass
10 second 10 Hz Jitter Bounce Pass
HD Jitter Readout Accuracy (HD)
Jitter Trace Pass
Jitter Readout Pass
External Reference Formats supported: Bi-Level
Pass
External Reference Lock Range
–50 ppm 50 ppm
External Reference Formats supported: Tri-Level
Pass
External Reference Lock in Presence of H um: Bi-Level
Pass
External Reference Lock in Presence of Hum: Tri-Level
Pass
46 Waveform Monitors Specifications and Performance Verification
