Fig. 3: Right hand side panel
Fig. 4: Left hand side panel
The connectors are as follows:
Side panel connectors
Item Description
A WiFi antenna connectors.
B 3G antenna connectors. These are not used on this router.
3.1.4 Bottom Panel
The following items can be found on the bottom panel:
Fig. 5: Bottom panel
The main items on the bottom panel are as follows.
bottom pANEL ELEMENTS TABLE
Item Description
A Internal 3G module SIM tray. Not used on this router.
B Adhesive rubber feet (not required for rack installation).
3 Components and Power Supply Teldat S.A.
6 Teldat Router Connect-104KF
