A.6.8 Power Supply
INPUT VOLTAGE +12V DC.
INPUT CURRENT 1200 mA
JACK 5.5 mm
INTERNAL PINOUT 2.5 mm
A.6.9 Dimensions and weight
TYPE Desktop / chassis for a 1 U high Rack mount enclosure
LENGTH x WIDTH x HEIGHT 245 x 210 x 45 mm.
WEIGHT 1.432 Kg.
A.6.10 Environmental Specifications
TEMPERATURA OPERATING NORMALLY: 0ºC to 45ºC
STORED: -25ºC to 70ºC
RELATIVE HUMIDITY On: 5% a 90%
Teldat S.A.
Technical information
Teldat Router Connect-104KF 17
