A.5.2 WAN Connector
WAN Connector
RJ45 WAN RJ45 Pinouts FE Signals GE Signals
1
2
3
4
5
6
7
8
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
A.5.3 WWAN Connector (female)
WWAN Connector
PINOUT ANT
Internal
External
RF in/out
GND
A.5.4 WLAN Connector (male)
WLAN Connector
PINOUT ANT
Internal
External
RF in/out
GND
Technical information Teldat S.A.
14 Teldat Router Connect-104KF
