BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
32
TIME-TO-WATER MASS LAYER BEAM 2
LSB
33
34
35 MSB
36
TIME-TO-WATER MASS LAYER BEAM 3
LSB
37
38
39 MSB
40
TIME-TO-WATER MASS LAYER BEAM 4
LSB
41
42
43 MSB
44
RANGE TO WATER MASS CELL
LSB
45 MSB
46
WATER TRACK STANDARD DEVIATION BEAM 1
LSB
47 MSB
48
WATER TRACK STANDARD DEVIATION BEAM 2
LSB
49 MSB
50
WATER TRACK STANDARD DEVIATION BEAM 3
LSB
51 MSB
52
WATER TRACK STANDARD DEVIATION BEAM 4
LSB
53 MSB
54
BOTTOM TRACK TIME-OF-VALIDITY BEAM 1
LSB
55
56
57 MSB
58
BOTTOM TRACK TIME-OF-VALIDITY BEAM 2
LSB
59
60
61 MSB
