Teledyne PATHFINDER - Figure 41. Navigation Parameters Data Format

Pathfinder DVL Guide April 2018
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
Page 199
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
62
BOTTOM TRACK TIME-OF-VALIDITY BEAM 3
LSB
63
64
65 MSB
66
BOTTOM TRACK TIME-OF-VALIDITY BEAM 4
LSB
67
68
69 MSB
70
WATER TRACK TIME-OF-VALIDITY BEAM 1
LSB
71
72
73 MSB
74
WATER TRACK TIME-OF-VALIDITY BEAM 2
LSB
75
76
77 MSB
78
WATER TRACK TIME-OF-VALIDITY BEAM 3
LSB
79
80
81 MSB
82
WATER TRACK TIME-OF-VALIDITY BEAM 4
LSB
83
84
85 MSB
Figure 41. Navigation Parameters Data Format
