Replaceable Parts
Use the following table to order replacement parts:
Table 15: Pathfinder ROV Spare Parts – Part of 75BK6084-00
Description Part number Where used
Anode, housing, top 81B-4146-00
Anodes for Housing Exterior
Anode, housing, bottom 810-4106-00
Anode Screw M5X0.8X10FH
Anode Screw M2.5X0.45X8FH
M4 Washer M4WASHSMOD
Closing hardware for housing
M4 Split Washer M4WASHSPL
M4 Nylon Washer M4WASHNYLON
M4 Nut M4X0.7NUT
Isolator 91145A148
M4 Bolt M4X0.7X25SH
Table 16. 75BK6087-00 – Kit, Field Service, ROV Pathfinder
P/N Description QTY
M4WASHSMOD
WASHER, SMALL OD, 8MM SST
14
M4WASHSPL
WASHER, SPLIT LOCK,SST
8
M4WASHNYLON
WASHER, FLAT,9MM OD,NYLON
8
M4X0.7NUT
NUT, HEX, SST
8
91145A148
ISOLATOR, 1/4 LONG, SCREW #8, NYLON
8
M4X0.7X25SH
SCREW, BUTTON/SOCKET HEAD 316 SST
8
81B-4146-00
ANODE, PIONEER 300
2
810-4106-00
ANODE, SMALL OD
4
M5X0.8X10FH
SCREW, FLAT HEAD, SST
2
M2.5X0.45X8FH
SCREW, FLAT HD SKT HD, 316SST
4
2-152
O-RING, -152, EPDM 70 DURO
2
97Z-6084-01
O-RING, 3-094, .072DIAX.351 ID, EPDM, DURO90A, VENT PLUG
2
7295K1
TIE WRAP, FASTENER MOUNT, 4.5
2
97Z-6007-00
O-RING, 2-011, DURO 70, EPDM
4
97Z-6009-00
O-RING, 2-014 DURO 70, EPDM
2
97Z-6036-00
O-RING, 2-166, 70 DURO,EPDM
2
97Z-6084-00
O-RING, 2-015, 070DIAX.551 ID, EPDM, DURO 90A, VENT PLUG
2
DES6
DESICCANT, SEALED BAG, 1/6 UNI
1
