T200UP INTERCONNECT LIST
(Reference: 0745701A DCN5833)
Cable Part
#
Signal Assembly PN J/P Pin Assembly PN J/P Pin
036490400 CBL, AC POWER
AC Line Power Entry CN0000073 L Power Switch SW0000025 L
AC Neutral Power Entry CN0000073 N Power Switch SW0000025 N
Power Grnd Power Entry CN0000073 Shield SW0000025
Power Grnd Power Entry CN0000073 Chassis
AC Line Switched Power Switch SW0000025 L PS2 (+12) 060820000 SK2 1
AC Neutral Switched Power Switch SW0000025 N PS2 (+12) 060820000 SK2 3
Power Grnd Power Entry CN0000073 PS2 (+12) 060820000 SK2 2
AC Line Switched Power Switch SW0000025 L PS3 (24V) PS0000044 SK2 1
AC Neutral Switched Power Switch SW0000025 N PS3 (24V) PS0000044 SK2 3
Power Grnd Power Entry CN0000073 PS3 (24V) PS0000044 SK2 2
AC Line Switched Power Switch SW0000025 L PS1 (+5, ±15) 068010000 SK2 1
AC Neutral Switched Power Switch SW0000025 N PS1 (+5, ±15) 068010000 SK2 3
Power Grnd Power Entry CN0000073 PS1 (+5, ±15) 068010000 SK2 2
AC Line Switched Power Switch SW0000025 L Relay PCA 045230100 J1 1
AC Neutral Switched Power Switch SW0000025 N Relay PCA 045230100 J1 3
Power Grnd Power Entry CN0000073 Relay PCA 045230100 J1 2
03829 CBL, DC POWER TO MOTHERBOARD
DGND Relay PCA 045230100 P7 1 Motherboard 058021100 P15 1
+5V Relay PCA 045230100 P7 2 Motherboard 058021100 P15 2
AGND Relay PCA 045230100 P7 3 Motherboard 058021100 P15 3
+15V Relay PCA 045230100 P7 4 Motherboard 058021100 P15 4
AGND Relay PCA 045230100 P7 5 Motherboard 058021100 P15 5
-15V Relay PCA 045230100 P7 6 Motherboard 058021100 P15 6
+12V RET Relay PCA 045230100 P7 7 Motherboard 058021100 P15 7
+12V Relay PCA 045230100 P7 8 Motherboard 058021100 P15 8
Chassis Gnd Relay PCA 045230100 P7 10 Motherboard 058021100 P15 9
04021 CBL, PREAMP, O2 SENSOR, O3 GEN, FAN, RELAY PCA & MOTHERBOARD
+15V Relay PCA 045230100 P12 4 Ozone generator 07228XXXX P1 4
AGND Relay PCA 045230100 P12 3 Ozone generator 07228XXXX P1 5
+12V Relay PCA 045230100 P12 8 PMT cooling fan 013140000 P1 1
+12V RET Relay PCA 045230100 P12 7 PMT cooling fan 013140000 P1 2
O3GEN enable signal Motherboard 058021100 P108 15 Ozone generator 07228XXXX P1 6
ETEST Motherboard 058021100 P108 8 Preamp PCA 041800600 P6 1
OTEST Motherboard 058021100 P108 16 Preamp PCA 041800600 P6 2
PHYSICAL RANGE Motherboard 058021100 P108 7 Preamp PCA 041800600 P6 4
PMT TEMP Motherboard 058021100 P109 4 Preamp PCA 041800600 P6 5
HVPS Motherboard 058021100 P109 5 Preamp PCA 041800600 P6 6
PMT SIGNAL+ Motherboard 058021100 P109 6 Preamp PCA 041800600 P6 7
AGND Motherboard 058021100 P109 11 Preamp PCA 041800600 P6 S
04022 CBL, DC POWER, FANM KEYBOARD, TEC, SENSOR PCA
TEC +12V TEC PCA 049310100 P1 1 Relay PCA 045230100 P10 8
TEC +12V RET TEC PCA 049310100 P1 2 Relay PCA 045230100 P10 7
DGND LCD Interface PCA 066970000 P14 8 Relay PCA 045230100 P10 1
+5V LCD Interface PCA 066970000 P14 1 Relay PCA 045230100 P10 2
DGND LCD Interface PCA 066970000 P14 2 Relay PCA 045230100 P11 1
+5V LCD Interface PCA 066970000 P14 3 Relay PCA 045230100 P11 2
+12V RET Chassis fan 040010000 P1 1 Relay PCA 045230100 P11 7
+12V Chassis fan 040010000 P1 2 Relay PCA 045230100 P11 8
P/Flow Sensor AGND P/Flow Sensor PCA 040030800 P1 3 Relay PCA 045230100 P11 3
P/Flow Sensor +15V P/Flow Sensor PCA 040030800 P1 6 Relay PCA 045230100 P11 4
Pressure signal 1 P/Flow Sensor PCA 040030800 P1 2 Motherboard 058021100 P110 6
Pressure signal 2 P/Flow Sensor PCA 040030800 P1 4 Motherboard 058021100 P110 5
Flow signal 1 P/Flow Sensor PCA 040030800 P1 5 Motherboard 058021100 P110 4
Flow signal 2 P/Flow Sensor PCA 040030800 P1 1 Motherboard 058021100 P110 3
Shield P/Flow Sensor PCA 040030800 P1 S Motherboard 058021100 P110 12
Shield Motherboard 058021100 P110 9 Relay PCA 045230100 P17 S
Thermocouple signal 1 Motherboard 058021100 P110 2 Relay PCA 045230100 P17 1
TC 1 signal DGND Motherboard 058021100 P110 8 Relay PCA 045230100 P17 2
Thermocouple signal 2 Motherboard 058021100 P110 1 Relay PCA 045230100 P17 3
TC 2 signal DGND Motherboard 058021100 P110 7 Relay PCA 045230100 P17 4
CONNECTION FROM CONNECTION TO
To Next Page
