T200UP INTERCONNECT LIST
(Reference: 0745701A DCN5833)
Cable Part
#
Signal Assembly PN J/P Pin Assembly PN J/P Pin
CONNECTION FROM CONNECTION TO
04023 CBL, I2C, RELAY PCA TO MOTHERBOARD
I2C Serial Clock Motherboard 058021100 P107 3 Relay PCA 045230100 P3 1
I2C Serial Data Motherboard 058021100 P107 5 Relay PCA 045230100 P3 2
I2C Reset Motherboard 058021100 P107 2 Relay PCA 045230100 P3 4
I2C Shield Motherboard 058021100 P107 6 Relay PCA 045230100 P3 5
04024 CBL, NOX, ZERO/SPAN, IZS VALVES
Zero/Span valve +12V Relay PCA 045230100 P4 1 Zero/Span valve 042680100 P1 1
Zero/Span valve +12V RET Relay PCA 045230100 P4 2 Zero/Span valve 042680100 P1 2
Sample valve +12V Relay PCA 045230100 P4 3 Sample valve 042680100 P1 1
Sample valve +12V RET Relay PCA 045230100 P4 4 Sample valve 042680100 P1 2
AutoZero valve +12V Relay PCA 045230100 P4 5 AutoZero valve 042680100 P1 1
AutoZero valve +12V RET Relay PCA 045230100 P4 6 AutoZero valve 042680100 P1 2
NONOx valve +12V Relay PCA 045230100 P4 7 NONOx valve 042680100 P1 1
NONOx valve +12V RET Relay PCA 045230100 P4 8 NONOx valve 042680100 P1 2
0402603 CBL, IZS & O2 SENSOR HEATERS/THERMISTORS, REACTION CELL & MANIFOLD THERMISTORS
Rcell thermistor A Motherboard 058021100 P27 7 Reaction cell thermistor 041920000 P1 2
Rcell thermistor B Motherboard 058021100 P27 14 Reaction cell thermistor 041920000 P1 1
CO2 thermistor A Motherboard 058021100 P27 6 CO2 thermistor/htr 06693 P1 2
CO2 thermistor B Motherboard 058021100 P27 13 CO2 thermistor/htr 06693 P1 3
CO2 heater L Relay PCA 045230100 P18 1 CO2 thermistor/htr 06693 P1 4
CO2 heater L Relay PCA 045230100 P18 2 CO2 thermistor/htr 06693 P1 1
CO2 heater L Relay PCA 045230100 P18 11
O2 sensor heater Relay PCA 045230100 P18 6 O2 sensor therm./heater 043420000 P1 4
O2 sensor heater Relay PCA 045230100 P18 7 O2 sensor therm./heater 043420000 P1 2
Shield Relay PCA 045230100 P18 12 O2 sensor therm./heater 043420000 P1
O2 sensor thermistor A Motherboard 058021100 P27 4 O2 sensor therm./heater 043420000 P1 3
O2 sensor thermistor B Motherboard 058021100 P27 11 O2 sensor therm./heater 043420000 P1 1
Byp/dil. man. thermistor A Motherboard 058021100 P27 1 Manifold thermistor 043420000 P1 1
Byp/dil. man. thermistor B Motherboard 058021100 P27 8 Manifold thermistor 043420000 P1 2
Configuration jumper intern. Relay PCA 045230100 P18 3 Relay PCA 045230100 P18 4
Configuration jumper intern. Relay PCA 045230100 P18 8 Relay PCA 045230100 P18 9
04027 CBL, NO2 CONVERTER, REACTION CELL & MANIFOLD HEATERS
Bypass/dil. manifold heater L Manifold heater 1 044340000 P1 1 Relay PCA 045230100 P2 11
Bypass/dil. manifold heater N Manifold heater 1 044340000 P1 2 Relay PCA 045230100 P2 12
Bypass/dil. manifold heater L Relay PCA 045230100 P2 11 Manifold heater 2 044340000 P1 1
Bypass/dil. manifold heater N Relay PCA 045230100 P2 15 Manifold heater 2 044340000 P1 2
Moly heater A Relay PCA 045230100 P2 7 Moly heater A 039700100 P1 1
Moly heater C Relay PCA 045230100 P2 6 Moly heater C 039700100 P1 2
Moly heater B Relay PCA 045230100 P2 10 Moly heater B 039700100 P1 3
Configuration jumper intern. Relay PCA 045230100 P2 13 Relay PCA 045230100 P2 14
Configuration jumper intern. Relay PCA 045230100 P2 8 Relay PCA 045230100 P2 9
Reaction cell heater/switch Relay PCA 045230100 P2 1 Reaction cell heater 1B 040400000 P1 4
Reaction cell heater/switch Relay PCA 045230100 P2 1 Reaction cell heater 2B 040400000 P1 6
Reaction cell heater/switch Relay PCA 045230100 P2 2 Reaction cell heater 1A 040400000 P1 3
Reaction cell heater/switch Relay PCA 045230100 P2 3 Reaction cell heat switch 040400000 P1 1
Reaction cell heater/switch Relay PCA 045230100 P2 4 Reaction cell heat switch 040400000 P1 2
Reaction cell heater/switch Relay PCA 045230100 P2 5 Reaction cell heater 2A 040400000 P1 5
04105 CBL, KEYBOARD, DISPLAY TO MOTHERBOARD
Kbd Interrupt LCD Interface PCA 066970000 J1 7 Motherboard 058021100 J106 1
DGND LCD Interface PCA 066970000 J1 2 Motherboard 058021100 J106 8
SDA LCD Interface PCA 066970000 J1 5 Motherboard 058021100 J106 2
SCL LCD Interface PCA 066970000 J1 6 Motherboard 058021100 J106 6
Shld LCD Interface PCA 066970000 J1 10 Motherboard 058021100 J106 5
04176 CBL, DC POWER TO RELAY PCA
DGND Relay PCA 045230100 P8 1 Power Supply Triple 068010000 J1 3
+5V Relay PCA 045230100 P8 2 Power Supply Triple 068010000 J1 1
+15V Relay PCA 045230100 P8 4 Power Supply Triple 068010000 J1 6
AGND Relay PCA 045230100 P8 5 Power Supply Triple 068010000 J1 4
-15V Relay PCA 045230100 P8 6 Power Supply Triple 068010000 J1 5
+12V RET Relay PCA 045230100 P8 7 Power Supply Single 068020000 J1 3
+12V Relay PCA 045230100 P8 8 Power Supply Single 068020000 J1 1
D-4
