T200UP INTERCONNECT LIST
(Reference: 0745701A DCN5833)
Cable Part
#
Signal Assembly PN J/P Pin Assembly PN J/P Pin
CONNECTION FROM CONNECTION TO
04433 CBL, PREAMPLIFIER TO RELAY PCA
Preamplifier DGND Relay PCA 045230100 P9 1 Preamp PCA 041800600 P5 1
Preamplifier +5V Relay PCA 045230100 P9 2 Preamp PCA 041800600 P5 2
Preamplifier AGND Relay PCA 045230100 P9 3 Preamp PCA 041800600 P5 3
Preamplifier +15V Relay PCA 045230100 P9 4 Preamp PCA 041800600 P5 4
Preamplifier -15V Relay PCA 045230100 P9 6 Preamp PCA 041800600 P5 6
04437 CBL, PREAMPLIFIER TO TEC
Preamp TEC drive VREF Preamp PCA 041800600 J1 1 TEC PCA 049310100 J3 1
Preamp TEC drive CTRL Preamp PCA 041800600 J1 2 TEC PCA 049310100 J3 2
Preamp TEC drive AGND Preamp PCA 041800600 J1 3 TEC PCA 049310100 J3 3
04671 CBL, MOTHERBOARD TO XMITTER BD (MULTIDROP OPTION)
GND Motherboard 058021100 P12 2 Xmitter bd w/Multidrop 069500000 J4 2
RX0 Motherboard 058021100 P12 14 Xmitter bd w/Multidrop 069500000 J4 14
RTS0 Motherboard 058021100 P12 13 Xmitter bd w/Multidrop 069500000 J4 13
TX0 Motherboard 058021100 P12 12 Xmitter bd w/Multidrop 069500000 J4 12
CTS0 Motherboard 058021100 P12 11 Xmitter bd w/Multidrop 069500000 J4 11
RS-GND0 Motherboard 058021100 P12 10 Xmitter bd w/Multidrop 069500000 J4 10
RTS1 Motherboard 058021100 P12 8 Xmitter bd w/Multidrop 069500000 J4 8
CTS1/485- Motherboard 058021100 P12 6 Xmitter bd w/Multidrop 069500000 J4 6
RX1 Motherboard 058021100 P12 9 Xmitter bd w/Multidrop 069500000 J4 9
TX1/485+ Motherboard 058021100 P12 7 Xmitter bd w/Multidrop 069500000 J4 7
RS-GND1 Motherboard 058021100 P12 5 Xmitter bd w/Multidrop 069500000 J4 5
RX1 Motherboard 058021100 P12 9 Xmitter bd w/Multidrop 069500000 J4 9
TX1/485+ Motherboard 058021100 P12 7 Xmitter bd w/Multidrop 069500000 J4 7
RS-GND1 Motherboard 058021100 P12 5 Xmitter bd w/Multidrop 069500000 J4 5
06737 CBL, I2C to AUX I/O (ANALOG IN OPTION)
ATX+ AUX I/O PCA 067300000 J2 1 Motherboard 058021100 J106 1
ATX- AUX I/O PCA 067300000 J2 2 Motherboard 058021100 J106 2
LED0 AUX I/O PCA 067300000 J2 3 Motherboard 058021100 J106 3
ARX+ AUX I/O PCA 067300000 J2 4 Motherboard 058021100 J106 4
ARX- AUX I/O PCA 067300000 J2 5 Motherboard 058021100 J106 5
LED0+ AUX I/O PCA 067300000 J2 6 Motherboard 058021100 J106 6
LED1+ AUX I/O PCA 067300000 J2 8 Motherboard 058021100 J106 8
06738 CBL, CPU COM to AUX I/O (USB OPTION)
RXD1 CPU PCA 067240000 COM1 1 AUX I/O PCA
0673000 or -02
J3 1
DCD1 CPU PCA 067240000 COM1 2 AUX I/O PCA
0673000 or -02
J3 2
DTR1 CPU PCA 067240000 COM1 3 AUX I/O PCA
0673000 or -02
J3 3
TXD1 CPU PCA 067240000 COM1 4 AUX I/O PCA
0673000 or -02
J3 4
DSR1 CPU PCA 067240000 COM1 5 AUX I/O PCA
0673000 or -02
J3 5
GND CPU PCA 067240000 COM1 6 AUX I/O PCA
0673000 or -02
J3 6
CTS1 CPU PCA 067240000 COM1 7 AUX I/O PCA
0673000 or -02
J3 7
RTS1 CPU PCA 067240000 COM1 8 AUX I/O PCA
0673000 or -02
J3 8
RI1 CPU PCA 067240000 COM1 10 AUX I/O PCA
0673000 or -02
J3 10
06738 CBL, CPU COM to AUX I/O (MULTIDROP OPTION)
RXD
CPU PCA
067240000
COM1 1
Xmitter bd w/Multidrop 069500000 J3
1
DCD
CPU PCA
067240000
COM1 2
Xmitter bd w/Multidrop 069500000 J3
2
DTR
CPU PCA
067240000
COM1 3
Xmitter bd w/Multidrop 069500000 J3
3
TXD
CPU PCA
067240000
COM1 4
Xmitter bd w/Multidrop 069500000 J3
4
DSR
CPU PCA
067240000
COM1 5
Xmitter bd w/Multidrop 069500000 J3
5
GND
CPU PCA
067240000
COM1 6
Xmitter bd w/Multidrop 069500000 J3
6
CTS
CPU PCA
067240000
COM1 7
Xmitter bd w/Multidrop 069500000 J3
7
RTS
CPU PCA
067240000
COM1 8
Xmitter bd w/Multidrop 069500000 J3
8
RI
CPU PCA
067240000
COM1 10
Xmitter bd w/Multidrop 069500000 J3
10
