T200UP INTERCONNECT LIST
(Reference: 0745701A DCN5833)
Cable Part
#
Signal Assembly PN J/P Pin Assembly PN J/P Pin
CONNECTION FROM CONNECTION TO
06739 CBL, CPU LAN TO AUX I/O PCA
ATX- CPU PCA 067240000 LAN 1 AUX I/O PCA
06730XXXX
J2 1
ATX+ CPU PCA 067240000 LAN 2 AUX I/O PCA
06730XXXX
J2 2
LED0 CPU PCA 067240000 LAN 3 AUX I/O PCA
06730XXXX
J2 3
ARX+ CPU PCA 067240000 LAN 4 AUX I/O PCA
06730XXXX
J2 4
ARX- CPU PCA 067240000 LAN 5 AUX I/O PCA
06730XXXX
J2 5
LED0+ CPU PCA 067240000 LAN 6 AUX I/O PCA
06730XXXX
J2 6
LED1 CPU PCA 067240000 LAN 7 AUX I/O PCA
06730XXXX
J2 7
LED1+ CPU PCA 067240000 LAN 8 AUX I/O PCA
06730XXXX
J2 8
06741
CBL, CPU USB to Front Panel
GND
CPU PCA 067240000
USB 8 LCD Interface PCA 066970000 JP9
LUSBD3+
CPU PCA 067240000
USB 6 LCD Interface PCA 066970000 JP9
LUSBD3-
CPU PCA 067240000
USB 4 LCD Interface PCA 066970000 JP9
VCC
CPU PCA 067240000
USB 2 LCD Interface PCA 066970000 JP9
06746 CBL, MB TO 06154 CPU
GND Motherboard 058021100 P12 2 Shield
RX0 Motherboard 058021100 P12 14 CPU PCA 067240000 COM1 1
RTS0 Motherboard 058021100 P12 13 CPU PCA 067240000 COM1 8
TX0 Motherboard 058021100 P12 12 CPU PCA 067240000 COM1 4
CTS0 Motherboard 058021100 P12 11 CPU PCA 067240000 COM1 7
RS-GND0 Motherboard 058021100 P12 10 CPU PCA 067240000 COM1 6
RTS1 Motherboard 058021100 P12 8 CPU PCA 067240000 COM2 8
CTS1/485- Motherboard 058021100 P12 6 CPU PCA 067240000 COM2 7
RX1 Motherboard 058021100 P12 9 CPU PCA 067240000 COM2 1
TX1/485+ Motherboard 058021100 P12 7 CPU PCA 067240000 COM2 4
RS-GND1 Motherboard 058021100 P12 5 CPU PCA 067240000 COM2 6
RX1 Motherboard 058021100 P12 9 CPU PCA 067240000 485 1
TX1/485+ Motherboard 058021100 P12 7 CPU PCA 067240000 485 2
RS-GND1 Motherboard 058021100 P12 5 CPU PCA 067240000 485 3
07452 CBL, PHOTOLYTIC DC PWR, T200UP
Relay PCA 045230100 P1 5 PS3 (24V) PS0000044 SK1 1
Relay PCA 045230100 P1 10 PS3 (24V) PS0000044 SK1 5
Relay PCA 045230100 P1 4 Relay PCA 045230100 P8 9
WR256 CBL, TRANSMITTER TO INTERFACE
LCD Interface PCA 066970000 J15 Transmitter PCA 068810000 J1
D-6
07450B DCN6495
