Page 33
Appendix B
DIP Switch Summary
Switch SettingsSwitches
ON OFF (Default)
SW1-1 − 1-4: Transmit Level (page 15)
(see Table 2-2 on page 15)
SW1-5: Receiver Dynamic Range
(page 16)
−10 to −43 dBm +3 to −30 dBm
SW1-6: TX Cable Equalizer (page 16) Enabled Disabled
SW1-7: RX Cable Equalizer (page 16) Enabled Disabled
SW1-8: Anti-streaming (page 16) Active Inactive
SW2-1: FSK Mode (page 18) V.23 Bell 202
SW2-2: Receiver Squelch (page 18)
(valid for FSK mode, 2-wire half-duplex
operation only)
Turnaround
Squelch (Bell
202): 8ms
Turnaround
Squelch (V.23):
150ms
Turnaround
Squelch (Bell 202):
0ms
Turnaround
Squelch (V.23):
0ms
SW2-3: FSK Soft Carrier (page 19) Disabled Enabled
SW2-4 and SW2-5: FSK RTS-CTS
Delay (page 19)
(see Table 2-4)
SW2-6: FSK CD Delay (page 20) 23ms 6ms
SW2-7: Remote Loopback (page 20) Enabled Disabled
SW2-8: Reserved (Test Only) (page 20) Test Normal
