Interface Connector Pin Assignments
Page 37
Interface Connector Pin Assignments
Leased Line Terminal Block Pin Assignments
This Pin
Number…
Corresponds to
This Signal
1Rx
2Rx
3Tx
4Tx
Back-to-Back Connection to a Second Modem
