Specifications
Page 36
Receiver
dynamic range: 0 to –30 dBm or –10 to –43 dBm
Operating
temperature: -40°C to +85°C
Power supply: Wide range switching power supply:
• DSP9612FP (AC version): 85 to 265Volts
AC, 50/60 Hz, single phase or 85 to 400
VDC
• DSP9612-LV (DC version):10 to 53 Volts
DC
Surge protection: Leased line, up to 15KV
Carrier control: Constant or switched, DIP switch selectable
Carrier loss
recovery: Train on Data
Throughput delay: Less than 10 milliseconds for fast polling.
Auto RTS: Support DTE without hardware RTS
(high speed only)
Anti-Streaming: 27-second timer to prevent transmitter lock-up
network
Mechanical Specifications
Enclosure: Aluminum with removable front and rear panels
Dimensions: 5.70” wide x 8.30” long x 1.50” high
Weight: 1.9 lbs.
Interface connectors
Leased line: 4-position screw terminal.
Data Terminal
Equipment: DB-25 female connector
