Telephonics RT-1601 RT - System Specifications; Rt-1601 Rt Unit; Da-1203 A Antenna Drive Assembly; Cp-113 K Control Panel

TM106101(8/01) RDR-1600 Pilot’s Guide
47
System Specifications (Cont.)
46 RDR-1600 Pilot’s Guide TM106101(8/01)
System Specifications
13.3CP-113K CONTROL PANEL
Environmental Qualification:DO-160A Env. Cat.
F1A/PKS/XXXXXXABABA
Altitude: 55,000 feet
Temperature: -20 degrees C. to +55 degrees C.
(-4 degrees F. to +131 degrees F.)
Cooling:
May be required as determined by ambient
temperature range in aircraft cockpit.
Mounting: Panel mounted, DZUS.
Weight: 1.7 lbs. maximum (0.77 kg)
TSO: C63c
Overall Dimensions
Height: 2.25 inches maximum (57.2 mm)
Width: 5.75 inches maximum (146.0 mm)
Length: 6.5 inches maximum (165.1 mm)
Input Power
Voltage +28 Vdc inputs per DO-160A
Category B. Two inputs available.
Power Draw Using 2.5 watts maximum electrical power drain
+28 Vdc Lighting from +28 Vdc power bus plus 7.5 watts
Power Bus maximum lighting power drain from
+28 Vdc lighting bus.
Power Draw using 5 Vac,10 watts maximum electrical and lighting
400 Hz Lighting
input power drain from +28 Vdc power bus.
Power Bus One milliamp power drain from 5 Vac
lighting bus (reference).
13.0SYSTEM SPECIFICATIONS
13.1RT-1601 RT UNIT
Frequency:9375 MHz Xmit/Rec; 9310 MHz BCN REC
RF Power Output:10 KW Peak Power
PRF/Pulse Width:Short Range Search 1500 P.P.S./0.2 sec
Long Range Search and Beacon; 200 P.P.S./2.35 sec
Altitude:50,000 ft.
Temperature:-50°C to +55°C
Size:5”w x 6-1/4”h x 13-7/8”d (1/2 ATRI)
Weight:16 lbs. (7.26 kg)
TSO:C63c
13.2DA-1203A ANTENNA DRIVE ASSEMBLY
Reflector Size:10”, 12”, or 18” Flat Plate
Scan Angle:120° or 60°
Tilt Angle:±15°
Scan Rate:28°/sec
Stabilization Accuracy:±1°
Altitude:50,000 ft.
Temperature:-50°C to +55°C
Weight:10”, 0.88 lbs. (4 Kgs), 12”; 1.1 lbs. (0.498 Kgs), 18”; 2.2 lbs.
(1.0 Kgs)
Drive Assembly:6.5 lbs. (2.95 Kgs)
Counterbalanced Drive Assembly:9.5 lbs. (4.32 Kgs)
TSO:C63b
