T ELEPHONICS C ORPORATION
TM115007 REV A (04/07) 5-3
USE OR DISCLOSURE OF DATA CONTAINED ON THIS PAGE IS SUBJECT TO THE
RESTRICTION ON THE TITLE PAGE OF THIS DOCUMENT.
C
OMMUNICATION S YSTEMS D IVISION
Table 5.3-1
Charge LED Indication
CURRENT STATUS RED LED GREEN LED
No Radio OFF OFF
Error including TPT with non-
rechargeable batteries
FLASHING 50% OFF
Charging OFF FLASHING 50%
Fully charged OFF ON
Radio detected, but charge status
from battery not yet updated
FLASHING 50% FLASHING 50%
5.4 BIT INDICATION
The display overlay consists of two LEDs (red and green) for BIT indication at each TPT plug-in
bracket. The BIT LED indications are shown Table 5.4-1.
Table 5.4-1
BIT LED Indications
CURRENT STATUS RED LED GREEN LED
No Radio OFF OFF
Error FLASHING 50% OFF
Performing BIT OFF FLASHING 50%
BIT OK OFF ON
Setting of Channel FLASHING 50% FLASHING 50%
5.5 TPT CHANNEL SELECTION
This procedure will set the channel for every TPT resident on the TSS. A single TPT cannot be
isolated and set individually.
On the TSS four segment display, use the up and down arrows to select the desired channel
for the TPTs.
Press and release ENTER key once to initiate the change setting. All TPT units will now be
set to the same channel.
