TAP SPECIFICATIONS
DESCRIPTION VALUE
FREQUENCY 2.4 GHz ISM band
RF POWER OUTPUT 100 mW (default)
1 - 100 mW (+20 dBM) factory programmable
RANGE Up to 1500 ft. (unobstructed line-of-sight)
DIMENSIONS 8.7 inches in length by 5.7 inches in width by 2.3
inches high
WEIGHT 2.9 lbs
POWER 9-33VDC nominal @ 1A max. Feed must have
1A fuse.
PHYSICAL CHANNEL SPACING 300 KHz
3 dB PHYSICAL CHANNEL
BANDWIDTH
192 KHz
MODULATION
π/4 DQPSK
PHYSICAL CHANNEL BIT RATE 384 Kbps
SPEECH ENCODING 32 Kbit/sec ADPCM
NUMBER OF CHANNELS 50
NUMBER OF USERS PER CHANNEL 31
NUMBER OF SIMULTANEOUS
SPEAKERS
6
SPREAD SPECTRUM Frequency hopping/50 HPS
OPERATING TEMPERATURE -40ºC to +55ºC
