LRU ID: TruLink Access Point (TAP)
LRU CONNECTOR: J2 Data Interface Protective Cap P/N: 8LTE02B09
CONNECTOR STD: MIL-C 38999
MS27468T09B35SN
MATING CONN.
MS27467T09B35PN
CONNECTOR MFG'R: SOURIAU MATING CONNECTOR MFG'R: SOURIAU
CONNECTOR P/N: 8LT7C09B35SN MATING CONNECTOR P/N: 8LT5C09B35PN
Signal
Name
Signal
Level
Signal
Freq
Pin
Number
Input/
Output
Technical
Specs
Signal
Description
RX
RS23
2
Max
115.2
kbit/s
4
Input/
Output
VT100 or ANSI
compatible. ASCII transfer
protocol.
8 bit data, 1 stop bit,
No parity, 38400 baud.
Asynchronous data
interface. This interface
consists of two RS-232
lines. The RS-232
transceiver is a
SP3232EEA from
SIPEX.
TX 6
GND 1
