T ELEPHONICS C ORPORATION
TM115007 REV A (04/07) B-5
USE OR DISCLOSURE OF DATA CONTAINED ON THIS PAGE IS SUBJECT TO THE
RESTRICTION ON THE TITLE PAGE OF THIS DOCUMENT.
C
OMMUNICATION S YSTEMS D IVISION
LRU ID: TruLink Access Point (TAP)
LRU CONNECTOR: J4 Data Interface Protective Cap P/N: 8LTE02B09
CONNECTOR STD: MIL-C 38999
MS27468T09B35SA
MATING CONN.
MS27467T09B35PA
CONNECTOR MFG'R: SOURIAU MATING CONNECTOR MFG'R: SOURIAU
CONNECTOR P/N: 8LT7C09B35SA MATING CONNECTOR P/N: 8LT5C09B35PA
Signal
Name
Signal
Level
Signal
Freq
Pin
Number
Input/
Output
Technical
Specs
Signal
Description
Data Hi
RS48
5
2
Mbps
6
Input/
Output
Not yet implemented High Speed Data Bus.
This interface consists of
two RS485 lines. The
RS485 transceiver is a
MAX3485 from MAXIM.
The direction is
configured by the FPGA.
The signals have over
voltage protection and
EMI-filters.
Data Lo 5
Clock Hi 4
Clock Lo 3
GND 1
