Telephonics Trulink - Page 55

T ELEPHONICS C ORPORATION
TM115007 REV A (04/07) B-7
USE OR DISCLOSURE OF DATA CONTAINED ON THIS PAGE IS SUBJECT TO THE
RESTRICTION ON THE TITLE PAGE OF THIS DOCUMENT.
C
OMMUNICATION S YSTEMS D IVISION
POWER
LRU ID: TruLink Access Point (TAP)
LRU CONNECTOR: Power
CONNECTOR STD: MIL-C 26482 MATING CONN.
MS3116E14-5S
CONNECTOR MFG'R: CANNON MATING CONNECTOR MFG'R: CANNON
CONNECTOR P/N: KPT02E-14-5P MATING CONNECTOR P/N: KPT06E14-5S
Signal
Name
Signal
Level
Signal
Freq
Pin
Number
Input/
Output
Technical
Specs
Signal
Description
+28VDC
DC
DC
A, B
Input
Fused protected 60V,
650mA.
Current consumption,
12V, without load: 4.8
mA.
PTC-resistor: 650 mA
Tranzorb: 39V
Supply voltage: 9 to 33
VDC.
User must protect with
1A circuit breaker.
+28VRTN DC DC C, D, E
ANTENNA
LRU ID: TruLink Access Point (TAP)
LRU CONNECTOR: ANT
CONNECTOR TNC FEMALE- MATING CONN.
CONNECTOR MFG'R: TBD MATING CONNECTOR MFG'R: TBD
CONNECTOR P/N: TBD (TNC FEMALE) MATING CONNECTOR P/N: TBD (TNC
MALE)
Signal
Name
Signal
Type
Pin
Number
Input/
Output
Technical
Specs
Signal
Description
Antenna
RF
Antenna
1
Input/Output
Frequency Range: 2,400
MHz to 2,484 MHz
RF transmit / receive
signal. Connection to a
50 Ohm antenna
