ECLIPSE 8/16/32/99 Series – User Operation Manual
20
3.8 Checking the Bypassed Zones
According the used keyboard, the indication for bypassed zones differs.
Keyboard
Indication and checking the bypassed zone
LED 8/
LED 16A
The BYPASS LED is lit. In order to check the bypassed zones, you need to
press the ENTER button once. The numbers of the bypassed zones are lit,
while the BYPASS LED blinks.
Note: The LED 8 keyboard has indication for bypassing 01 to 08, and LED
16A – for 01 to 16 zones.
If there are bypassed zones out of their range
(Eclipse 32/99), they are not shown on the screen.
LED 32
The BYPASS button is lit. In order to check the bypassed zones, you need
to press the BYPASS button once. The numbers of the bypassed zones
are lit, while the BYPASS button blinks.
Note: The LED 32 keyboard has indication for bypassing 01 to 32 zones. If
there are bypassed zones out of its range (Eclipse 99), they are not shown
on the screen.
LCD 32/
LCD 32
Sensitive
The BYPASS button is lit. In order to check the bypassed zones, you need
to press the BYPASS button once. Information about the first bypassed
zone is shown on the display, while the other zones can be checked with
the arrow buttons, the BYPASS button blinks.
4. USERS’ PROGRAMMING MENUS
There are no default codes for ordinary users in the system. The Manager in the system
can set new codes and allow certain users to have manager rights (for ECLIPSE 32/99).
To enter user programming mode, enter in consecutive order:
* Code without manager rights.
Quick table for Users’ Programming Menu
Text Menus
Address
Number
Programming
parameter
ECLIPSE Control Panel
8
16
32
99
1. User Code Change
1
Changing own code




2. View Log
2
Memory LOG view




3. Chime
3
Chime Enable/Disable




4. Zone Bypass
4
Zone bypassing




5. User Card
5
Add/Delete own proxy card




Code*
Select a programming menu/
address number
