4. INPUTS – 5. ZONES – 01. ZONE – 9. LINE RESIST
Checking the line resistance
The engineer can check the line resistance of the zone at this address. It is suitable to perform
diagnostics of the zone troubles. The displayed value can vary according the used hardware
connection style in the system and has the following meaning:
Connection style
Displayed value
Description
Single zone connection
1
< 1.5 kΩ
The zone is closed.
> 1.5 kΩ
The zone is open.
2
< 0.75 kΩ
The zone is open.
0.75 – 1.5 kΩ
The zone is closed.
> 1.5 kΩ
The zone is open.
3
< 0.75 kΩ
The zone is open.
0.75 – 1.5 kΩ
The zone is closed.
> 1.5 kΩ
The zone is open.
4
< 0.75 kΩ
The zone is closed.
0.75 – 5.6 kΩ
The zone is open.
> 5.6 kΩ
Tamper break down.
5
< 0.75 kΩ
Tamper short-circuit.
0.75 – 1.5 kΩ
The zone is closed.
1.5 - 5.6 kΩ
The zone is open.
> 5.6 kΩ
Tamper break down.
Double zone connection
6
< 0.5 kΩ
The both zones are closed.
0.5 – 1.5 kΩ
The 1
st
zone is open, the 2
nd
zone is closed.
1.5 – 2.7 kΩ
The 1
st
zone is closed, the 2
nd
zone is open.
2.7 kΩ - ∞
The both zones are open.
7
< 0.5 kΩ
The both zones are closed.
0.5 – 1.5 kΩ
The 1
st
zone is open, the 2
nd
zone is closed.
1.5 – 2.7 kΩ
The 1
st
zone is closed, the 2
nd
zone is open.
2.7 – 4.9 kΩ
The both zones are open.
> 4.9 kΩ
Tamper break down.
8
< 0.75 kΩ
Tamper short-circuit.
0.75 – 1.5 kΩ
The both zones are closed.
1.5 – 2.5 kΩ
The 1
st
zone is open, the 2
nd
zone is closed.
2.5 – 3.7 kΩ
The 1
st
zone is closed, the 2
nd
zone is open.
3.7 – 4.9 kΩ
The both zones are open.
> 4.9 kΩ
Tamper break down.
9
< 0.5 kΩ
Tamper short-circuit.
0.5 - 0.75 kΩ
The both zones are closed.
0.75 - 1.5 kΩ
The 1
st
zone is closed, the 2
nd
zone is open.
1.5 – 2.7 kΩ
The 1
st
zone is open, the 2
nd
zone is closed.
> 2.7 kΩ
The both zones are open.
See also APPENDIX 6.
The ZONES with numbers from 02 to 08 for ECLIPSE 8, from 02 to 16 for ECLIPSE 16 and from 02 to 32 for ECLIPSE
32 are programmed in an analogical way.
