Eclipse 8/ 16/ 32 Series - Engineer Programming Manual
45
3. PGM Outputs
In “PGM Outputs” menu, the engineer programs some parameters and settings for the programmable outputs in the
system.
Some of the addresses are available for programming only with LCD keyboard!
Attention: In Eclipse 32 control panel, the PGM5 output is powerful (up to 1А) and is set by default as a monitored
output for siren connection. If after the initial power-up no siren is connected to the PGM5 output, the system will
display a system trouble “8. SIREN FAULT”. In case the PGM5 is not used for siren connection it has to be terminated
with 1kOm resistance or programmed as general output at address 3051. See also the example below the description
of address 3011.
ECLIPSE Control Panels Series – PGM capability:
Control panel
Max. PGM outputs
Power output, up to 1A
ECLIPSE 8
5
1 (PGM 5), non-monitored
ECLIPSE 16
5
1 (PGM 5), non-monitored
ECLIPSE 32
32
1 (PGM 5), monitored
Quick table for 3. PGM Outputs Programming Menu
Address Number
Programming parameter
ECLIPSE 8
ECLIPSE 16
ECLIPSE 32
3
0
0
0
PGM 04 Option



3
0
1
0
PGM 01 Attach



3
0
1
1
PGM 01 Options



3
0
1
2
PGM 01 Areas



3
0
1
3
PGM 01 Activation event



3
0
1
4
PGM 01 Activation event – Param 1



3
0
1
5
PGM 01 Activation event – Param 2



3
0
1
7
PGM 01 De-activation timer



3
0
1
9
PGM 01 Delay



3
0
2
0
PGM 02 Attach



3
0
2
1
PGM 02 Options



3
0
2
2
PGM 02 Areas



3
0
2
3
PGM 02 Activation event



3
0
2
4
PGM 02 Activation event – Param 1



3
0
2
5
PGM 02 Activation event – Param 2



3
0
2
7
PGM 02 De-activation timer



3
0
2
9
PGM 02 Delay



…
3
3
2
0
PGM 32 Attach



3
3
2
1
PGM 32 Options



3
3
2
2
PGM 32 Areas



3
3
2
3
PGM 32 Activation event



3
3
2
4
PGM 32 Activation event – Param 1



3
3
2
5
PGM 32 Activation event – Param 2



3
3
2
7
PGM 32 De-activation timer



3
3
2
9
PGM 32 Delay



