Eclipse 8/16/32/99 Series - Installation Manual
38
Text Menu
Address Menu
Eclipse 8
Eclipse 16
Eclipse 32
Eclipse 99
5. Options 2
2XX5
3.Report Only/
6.Chime/
8.Power Up Delay
3.Report Only/
6.Chime/
7.Pulse Count/
8.Power Up Delay
1.Bell Delay/2.Fire Delay/3.Report Only/
4.Video on Armed/5.Write to log/
6.Chime/7.Pulse Count/
8.Power Up Delay
6. Key Switch
2XX6
1.Pulse-Latch/2-3.Key Switch Arming types (Disabled, Full, Stay, Sleep)/
4.Disarm/5.Normal-Invert/6.Ignore Exit Time
7. Auxiliary
2XX7
-
-
0.24h Burglary/1.AC Loss/2.Batt Low/
3.Water Leakage/4.Gas Detector/
5.GSM Link Trouble/6.Low Bottled Gas
Level/7.High Temp/8.Low Temp/
9.Loss of Heat
8. Name
2XX8
Enter a unique name for the Zone. The menu is accessible via LCD keyboard.
9. Line Resistance
2XX9
Menu for viewing the resistance of the line.
6. Zone clone
2005
-
-
Copying zone options from one to more.
5. Outputs
1. PGM Option (PGM 4)
3000
Serial Link
-
Fire Output
Fire Output
2. PGMs
3XXY
Programming of outputs options; XX - PGM number; Y - option number.
XX. PGM
3XXY
XX: 1-5
XX: 1-8
XX: 1-32
XX: 1-99
1. Attach
3XX0
-
[DD] [PP] – DD: device number; PP: PGM number;
Note: PGMs 1-5 are fixed and they correspond to the numbers
of the hardware outputs of the control panel.
PGM numbers from 06 and higher are freely programmable.
2. Options
3XX1
1.General-Siren Output/
2.Polarity Normal-Invert
1.General-Siren Output/2.Polarity Normal-
Invert/3.Delay sec-min/4.Pulsed Fire
Enabled/5.Deact. Timer sec-min
3. Areas
3XX2
-
1-3
1-8
1-16
4. Activation
3XX3
Set an activation event type, see the Programming manual for details.
5. Act. Parameter 1
3XX4
Set Parameters 1 for activation event.
6. Act. Parameter 2
3XX5
Set Parameters 2 for activation event.
7. Deact. Timer
3XX7
-
-
Enter time 000-255 sec-min (depends on
the set unit in 2.Options-5). Default:000
8. Delay
3XX9
-
-
Enter time 000-255 sec-min (depends on
the set unit in 2.Options-3). Default:000
6. Partitions
1. Account Length
4000
[4/6]
2. Double Knock
4001
1-5 min. Default: 3 min
3. No Move on ARM
4002
-
-
Enter time 001-255 min.
Default: 000 (the option is disabled)
4. Postpone Time
4003
-
-
Enter time 010-255 min. Default:010
5. Areas
4XXY
Programming of areas options; XX - area number; Y - option number.
XX. Area
4XXY
XX: 01
XX: 01-03
XX: 01-08
XX: 01-16
01. Exit Time
4XX0
Enter exit time duration 000-255 sec. Default: 045
02. Entry Time
4XX1
Enter the Entry time 1 and Entry time 2 duration 000-255 sec. Default: 015
Note: In Eclipse 32/99 control panels the duration of entry times is limited up to 45
seconds, when the requirements of EN50131 for Grade 2 or Grade 3 are applied –
see menu 2. Settings → 15. Standard (address 0096).
03. Alarm Cycle
4XX2
Enter the duration of the Alarm cycle for siren outputs 000-255 sec. Default:001
04. Account
4XX3
Enter a 4/6-digit account number for communication. Default: FFFF
05. Bell Options
4XX4
1.Squawk on Arm/2.Squawk on Disarm/
5. Fire alarm duration
1.Squawk on Arm/2.Squawk on Disarm/
3.Alarm memory squawk/
4. 10 min. warning/
5. Fire alarm duration
06. ON/OFF Options
4XX5
3.Clear Bypass on Disarm/
4.Quick Arm
1.Disarm on Timeslot/
2.Auto Arm: Full-Stay/
3.Clear Bypass on Disarm/4.Quick Arm/
5.Auto Arm on no movement
07. Panics
4XX6
1. Enable Police Panic/2.Police Panic Sound type: Audible-Silent/3. Enable Medical
Panic/4.Medical Panic Sound type: Audible-Silent/5.Enable Fire Panic
08. Name
4XX7
-
Enter a unique name for the Area.
The menu is accessible via LCD keyboard.
09. Bell Delay
4XX8
-
-
Enter time 000-255 sec. Default: 000
10. Time Slot
4XX9
-
-
01-08
01-16
7. Schedules
1. Timeslots
5XXY
-
-
Programming of Timeslots;
XX - timeslot number; Y - option.
XX. Timeslot
5XXY
XX: 01-08
XX: 01-16
1. Start
5XX0
Enter start time for the timeslot.
