TELEVAC MM200 - Page 158

INSTRUMENT MANUAL
VACUUM GAUGE MODEL MM200
160Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
MM-200_im REV M
Page 157 of 160
TELEVAC
cable
Suppressor
Order #
1-6400-064*
905 SUPPRESOR INSTALLATION FOR NOISY ENVIROMENTS
For noisy environments, add suppressor to cable as shown. One suppressor is required for each cable.
* 3D & 3E module only use 1-6400-063
6 to 12 in.
Vacuum instrument
To gauge at vacuum
chamber
