Table 3.1a - Examples of Allowable Configurations for the MM200
MAX MAX MAX MAX
# # # #
STATIONS RELAYS STATIONS RELAYS
EPLANATION OF TERMS USED
2X = Dual station Thermocouple, Convection, Diaphragm, 7F Cold Cathode or single slot 7E cold
cathode
CC = Single station (two slot) Cold Cathode module (** shared space with RS232)
4S = Four setpoint module - * Can substitute for a 2X module
RS = RS232 or RS485
HC = Resident Hot Cathode module
10 8*
9 8*
MAX MAX
# #
STATIONS RELAYS
MAX MAX
# #
STATIONS RELAYS
8 8*
8 4*
MAX MAX
# #
STATIONS RELAYS
5 8*
