INSTRUMENT MANUAL
VACUUM GAUGE MODEL MM200
160Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
MM-200_im REV M
Page 37 of 160
TELEVAC
Software ver. 2.31 or higher)
MINI-BA GAUGE TO 3F MODULE WIRING DIAGRAM
